Spot Extractor


The Spot Extractor is a compact and efficient localized fume extraction system designed to remove harmful vapors, gases, smoke, or particulates directly from the point of origin. Constructed from durable polypropylene, it features a **flexible, articulated arm** that can be easily positioned to target specific work areas.

One end of the extractor is securely mounted on a ceiling, wall, or workstation, and is connected to a blower or ducting system. The opposite end is fitted with a **dome-shaped suction head**, designed to effectively capture and draw away airborne contaminants. For optimal performance, it should be installed approximately **1 foot above the fume source**.

Spot Extractor
Technical Specifications of Spot Extractor

Material: High-grade Polypropylene (PP)
Mounting Options: Wall-mounted, Ceiling-mounted, or Bench-mounted
Arm Length: Adjustable – typically 600mm to 1500mm
Diameter of Suction Arm: 75mm / 100mm
Suction Head: Dome-shaped, chemical-resistant
Airflow Connection: Ducted to blower or central exhaust system

Accessories

Wall/Ceiling Mount Brackets
Flexible PP Suction Arm with adjustable joints
Dome or Funnel-type Suction Nozzles
Optional Transparent Hood Attachment
In-line Blower or Connection to Central Exhaust
Dampers or Flow Regulators
